LiFePO4 Battery Pack 3.2V 7600mAh (26650 -1S2P)

LiFePO4 Battery Pack 3.2V 7600mAh (26650 -1S2P)
LiFePO4 Battery Pack 3.2V 7600mAh (26650 -1S2P) - Image 2
LiFePO4 Battery Pack 3.2V 7600mAh (26650 -1S2P) - Image 3
LiFePO4 Battery Pack 3.2V 7600mAh (26650 -1S2P) - Image 4
Category

Basic Information

ChemistryLiFePO4
Voltage3.2V
Capacity7600mAh (@0.5C discharge)
Energy24.32Wh
Dimension68(L)x28(W)x53(H)mm
Weight≤40mΩ
Send a inquiry

Description

  • The LiFePO4 26650 battery cell in this battery pack is UL, CB, UN38.3 certificated.
  • Long Lifespan
    During our lab testing, the 26650 cell is charged and discharged in 100% DOD for 2500 cycles, and the capacity retention is more than 80%
  • Flexible Battery Pack Design
    We develop battery packs according to customers’ requirements, customized structure, enclosure, BMS, we’ll make sure the batteries are suitable and reliable to your projects.

Product Datasheet

ItemsParameters
Nominal Voltage3.2V
Rated Capacity7600mAh (@0.5C discharge)
Rated Energy24.32Wh
Maximum Continuous Output Power15W
Impedance @AC 1000Hz≤40mΩ
Cycle Life @1C, 100%DOD, 80% Retention, 25℃>2000 cycles
Recharging Voltage3.65VDC
Charge ModeCC/CV
Maximum Charging Current3.8A
Continuous Output Current≤3.8A (changeable)
Peak Output Current8±2A (@10±5ms)
Discharge Cut-off Voltage4V
Cell & Configuration26650 3.2V 3800mAh in 1S2P
Housing MaterialPVC Shrinking
Dimension68(L)x28(W)x53(H)mm
WeightApprox. 180g
Charge Terminalcustomized
Discharge Terminalcustomized
Recharge Operation Temperature0~45℃
Discharge Operation Temperature-20~65℃
Storage Temperature-20~45℃
